GLL3300/22 /B chain feeder

Introduction of GLL3300/22/B chain coal feeder

GLL3300/22 / B chain coal feeder is a kind of specific mining, iron and steel industry such as research and development of a new series of feed products, mining, iron and steel industry, coal, ore, half coal rock or other materials in the feeding, easy to cause damage to belt feeder, belt damage rate is higher, in particular, cause material can't realize the problem of feeding in the delivery. Aiming at the above problems, our company organized researchers to develop a chain feeder, which completely solved the above problems.

Gll3300/22 /B chain coal feeder installation instructions

1. When the feeder is in use, enough coal should be stored in the bunker to avoid direct impact on the floor when the coal is loaded into the bunker.

2. Check whether the parts are loose or abnormal after monthly continuous work.

3. The transmission parts shall be checked every six months in a row. The parts of the pull rod must be kept in normal coordination.

4. All rotating parts shall be oiled once a month and checked once a quarter to observe the damage degree of bearings and seals and replace them in time when problems are found.

5. Maintenance of major components:

(1) Reduction gear

Check every six months, and clean or replace the lubricating oil on the rolling bearings and housing.

(2) Electric motors

According to the motor maintenance requirements.

Users' attention: lubricate moving parts regularly, check the running condition of each part, find out the reason in time and deal with the abnormal situation, and notify the manufacturer to deal with it if necessary; Close the gate when the empty warehouse is being repaired.

GLL3300/22/B chain coal feeder parameters

Power KW: 22

Voltage AC V: 380/660/1140

Maximum feed t/h: 3300

Maximum chain speed m/s: 0.7

Speed regulation: frequency converter variable speed continuously

Weight /kg: 5500

External dimension /mm (length × width × height) : 3715×2009×2225

GLL3300/22/B chain coal feeder
