Mine lithium ion power battery industry's first truly on-line exchange lithium iron phosphate battery power output, equipment advanced lithium-ion battery management technology, hi...
Introduction of lithium ion battery power supply for mine
Mine lithium ion power battery industry's first truly on-line exchange lithium iron phosphate battery power output, equipment advanced lithium-ion battery management technology, high-power ac inverter technology, ac voltage regulator uninterrupted power supply technology, large LCD display technology, remote monitoring management technology, downhole monitoring system integration of standby power supply is the best solution. This series of products are mainly used in: monitoring and monitoring system, downhole communication lighting, lighting system, downhole power supply control system, downhole voice broadcast communication system, downhole emergency communication, and other downhole electrical occasions.
Power supply parameters of lithium ion battery for mine
project |
DXBL1536/127J |
DXBL1536/220J |
DXBL2880/127J |
DXBL2880/220J |
Nominal battery capacity |
40Ah |
40Ah |
60Ah |
60Ah |
Battery rated charging voltage |
2.5V |
2.5V |
6V |
6V |
Battery pack overcurrent protection value |
6A |
6A |
8A |
8A |
Battery pack rated discharge current |
8A |
8A |
15A |
15A |
Battery discharge overcurrent protection value |
12A |
12A |
20A |
20A |
Minimum allowable battery capacity alarm value |
28Ah |
28Ah |
40Ah |
40Ah |
Rated output voltage of power supply |
127V |
220V |
127V |
220V |
Rated output current of power supply |
2.5A |
1.5 A |
5A |
3A |
Power output short circuit protection |
≤50ms |
≤50ms |
≤50ms |
≤50ms |
Power supply rated input voltage range |
660V/127V(-25%~10%) |
660V/127V(-25%~10%) |
660V/127V(-25%~10%) |
660V/127V(-25%~10%) |
Function and characteristics of lithium ion battery power supply for mine
Support four input voltage (AC660V, 380 v, 220 v, 127 v) power supply isolation, optimization of output power, isolated power grid pollution sources of internal modular design, seamless backup battery switch intelligent battery management system, maximize the lithium battery life support multiple interface input, output, continuous high quality voltage power network management platform design scheme, realize remote monitoring management functions, support the remote discharge over temperature protection, overshoot charging protection, discharge protection, over current protection, output short circuit protection, over-current protection standby power integration solution, greatly simplifying the system structure, cost savings.
Physical picture of lithium ion battery power supply for mine
